Electroplating High Temperature Blue Film Tape is a high temperature blue film tape specially designed for the electroplating industry, made of PVC material, with excellent electroplating protection properties.
1. Product introduction
Electroplating High Temperature Blue Film Tape is a high temperature blue film tape specially designed for the electroplating industry, made of PVC material, with excellent electroplating protection properties. This product combines high temperature resistance and excellent bonding properties to provide effective protection for metal surfaces during electroplating. The following is a detailed introduction to the features, advantages, product features, performance indicators, use methods and application fields of the product.
2. Product characteristics
High temperature resistance: able to maintain stable physical properties and bonding effects at temperatures up to 120°C.
Excellent adhesion: The special adhesive formulation ensures a strong adhesion between the tape and the surface of the electroplated part.
Plating protection: Specially designed blue film can effectively prevent contamination and oxidation during plating.
Easy to remove: the tape can be easily removed after use, leaving no residual glue.
Good chemical stability: good resistance to acid, alkali, salt spray and other corrosive media.
3. Product advantages
Improve plating quality: effectively protect plating parts, reduce defects, improve product appearance.
Cost savings: High temperature resistance reduces the frequency of replacement and reduces the cost of use.
Easy to operate: easy to stick and tear, improve work efficiency.
Environmental safety: no harmful substances, in line with RoHS standards, friendly to the human body and the environment.
4. Product characteristics
Yellow film: easy to identify, avoid misoperation.
High temperature adaptability: suitable for a variety of high temperature electroplating environments.
Strength and toughness: the tape has a certain strength and toughness, adapt to different shapes of electroplating parts.
5. Performance indicators
Material: PVC (polyvinyl chloride)
Color: Yellow or black
Thickness: 0.05mm - 0.2mm (can be customized according to demand)
Width: 10mm-1000mm (can be customized)
Temperature range: -20°C to 120°C
Bonding strength: ≥10N/25mm
Tear strength: ≥1.5N/25mm
Tensile strength: ≥30N/cm
6. FAQ
What is electroplated high temperature blue PVC protective film tape?
Electroplated high temperature blue PVC protective film tape is a protective film used in circuit board electroplating process, usually made of PVC film as a substrate, coated with pressure sensitive adhesive, with acid and alkali resistance, corrosion resistance and no residual adhesive characteristics.
What is the temperature range of this tape?
According to the product description, the tape can withstand long-term temperatures of 120ºC and short-term temperatures of up to 180ºC.
Can the size of the tape be customized?
Yes, the size of the tape can be customized according to the customer's needs, including width and length.
What is the thickness of this tape?
The thickness of the tape is usually 95±10μm, but the specific thickness can be adjusted according to customer needs.
How sticky is the tape?
The tape uses rubber pressure sensitive adhesive, which has good viscosity and is easy to tear and paste.
What are the application scenarios of this tape?
It is mainly used for the protection of circuit board plating process, and can also be used for other occasions requiring high temperature protection.
What are the characteristics of this tape?
With acid and alkali resistance, corrosion resistance, no residual rubber characteristics, suitable for special protection needs.
What is the base material of the tape?
The base material of the tape is PVC film.
